Rohr des nahtlosen Stahls

ST52 E355 PTO CARDAN SHAFT TRIANGLE LEMON SHAPE SHAFT LEMON TUBE FOR AGRICULTURAL DRIVE SHAFT SYSTEM Chemical Compositions: Standard Steel Grade C Si Mn P S EN 10305-1 E215 ≤0.10 ≤0.05 ≤0.70 ≤0.025 ≤0.025 E235 ≤0.17 ≤0.35 ≤1.20 ≤0.025 ≤0.025 E355 ≤0.22 ≤0.55 ≤1.60 ≤0.025 ≤0.025 DIN 2391 St35 ≤0.17 ≤0.35 ≥0.40 ≤0.025 ≤0.025 St37.4 ≤0.17 ≤0.35 ≥0.40 ≤0.025 ≤0.025 St45 ≤0.21 ≤0.35 ≥0.40 ≤0.025 ≤0.025 St52 ≤0.22 ≤0.55 ≤1.60 ≤0.025 ≤0.025 GB/T 3639 10 0.07-0.13 0.17-0.37 0.35-0.65

SAE1045 Cold Drawn Inside Hexagon Tube Hexagonal Special Steel Pipe for Machine Engineering Hexagonal/Hex Steel Tube/Steel Hex tubing Material :Carbon steel +Stainless steel or others Shape:Outside hexagonal steel tubes, intside round steel tubes Other shape: Outside Hexagonal Inside Round Seamless Steel Tubes Ellipse oval steel tubes Special shapes seamless steel tubes Rectangle steel tubes Keywords Hexagonal/Hex Steel Tube/Steel Hex tubing Material SAE1010 , SAE1020 ,

Products Description TORICH EN10210-1 Hot Finished Heavy Wall Steel Tubing for General Engineering Purpose Standard EN10210-1 Hot finished structural hollow sections of non-alloy and fine grain steels Part 1: Technical delivery conditions Part 2: Tolerances, dimensions and sectional properties Cold forming Process is done at ambient temperature Application For Construction & Decoration, For General Engineering Purposes Manufacture Structural hollow sections are manufactured

1 Product: seamless pipe 2 Standard : U.S.A. ASTM A53/A106/A178/A179/A192/A210/A213/A333/A335/A283/A135/A214/315/A500/A501/A519/A161/A334; API 5L/5CT Japan JIS G3452/G3454/G3456/G3457/G3458/G3460/3461/3462/3464 German DIN 1626/17175/1629-4/2448/2391/17200 SEW680 Britain BS 1387/1600/1717/1640/3601/3602/3059/1775 Russia GOST 8732/8731/3183 China GB/T8162/T8163 GB5310/6579/9948 3 Material and Grade U.S.A. Gr. B/Gr.A/A179/A192/A-1/T11/T12/T22/P1/FP1/T5/4140/4130 Japan STPG38

EN10126-2 Seamless Steel Tubes For Pressure Purposes-Technical Delivery Conditions EN10126-2 Seamless Steel Tubes For Pressure Purposes-Technical Delivery Conditions Size Range: O.D 5-420mm W.T 0.5-50mm L max12000mm Application: for manufacturing pipelines of boilers,vissel equipment Steel ,Chemical Composition & EN10216-2 Grade C Si Mn P S Cr Mo Mpa Mpa L T 195GH ≤0.13 ≤0.35 ≤0.70 ≤0.025 ≤0.020 ≤0.30 ≤0.08 320-440 ≥195 ≥27 ≥25 P235GH ≤0.16 ≤0.35 ≤1.2 ≤0.025 ≤0.020 ≤0.30 ≤0

Ferritic / Austenitic Alloy Seamless Steel Tube Polishing Surface 3.2 - 127mm OD ASTM A213/A213M-18 seamless ferritic and austenitic alloy-steel tubes are designed for pressure-bearing heat transfer service where dimensional stability, clean internal surface condition, and reliable elevated-temperature performance matter. In this category, the most commonly specified austenitic grades include TP304, TP304L, TP316L, TP321, and TP347H, covering general heat-exchanger duty,

EN10305-1/ASTM A513 Cold Drawn Heavy Wall Mechanical Seamless Honed Tube Standard: ASTM A513 Grade Group: A53-A369 Thickness: 0.5 - 50 mm Outer Diameter(Round): 5 - 420 mm Surface Treatment: Bright Technique: Cold Drawn, Cold Drawing Material: SAE1010,SAE1020,SAE1026,SAE4130,SAE4140 L: max12000mm 1. ASTM A519 Oil cylinder Seamless Carbon and Alloy Steel Mechanical Tubing 2. Steel Grade: SAE1010,SAE1020,SAE1026,SAE4130,SAE4140 3. Porudction Method: Cold drawing + Honing +

Products Description TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube Standard DIN17175, DIN2391 Material 20#, 45#, Q345 Size OD: 5-120mm WT: 0.5-50 Length: 3-9m Delivery Condition + Cc + LCc + SR + Ad + N Test Tensile Test, Hydraulic Test, Eddy Current Test etc Application Hydraulic Pipe Mechanical Requirements Delivery Condition Cold Finished (Hard) (BK) Cold Drawn and Stress-Relieved (BK+S) Hardness HB Parameters T.S. Rm N/mm2 Elongation A5%

Hydraulic Cylinder Tube E355 ST52 H8 Honed Tube Manufacture Method: Cold drawn, hot rolled+deep hole bored Certification: ISO9001, SGS, Material: Carbon steel,alloy steel, stainless steel Standard&Grade: DIN2391-2 ST52,EN10305-1 E355,C45E,25CrMo4,42CrMo4, CK45,E410, E470,ASTM A519 SAE1020,SAE1026,SAE1045,SAE1518,SAE1541, SAE4130,SAE4140,SAE4145,SAE4340,etc. Size Range: ID of 300mm max for cold drawing, ID of 500mm for deep hole boring ID Tolerance: ISO H8 End finish: Plain
