Geschweißtes Stahlrohr

Welded Carbon Steel Flat Sided Elliptical Oval Tube Standard GB/T3094, BS, JIS, GB, DIN, ASTM, API Matrial 10#-45# A53-A369, ST35-ST52, Q195, Q235 , Q345 Size OD: 4-1200mm WT: 0.3-200mm Length: 1-12m Application Mechanical engineering , Agricultural machines , Structural construction Surface painted,galvanized,or oiled according to customer's requirement Test and Inspection Mechanical Test, Tension Test Flaring Test, Flattening Test Hardness Test, Hydrostatic or Nondestructiv

OD127mm*WT1.5mm ERW Steel Tubes with Erased Seam for Heavy Truck Exhaust System ASTM A513 Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing Size : O.D.:6-350mm W.T.:1-12.5mm L:max12000mm Grade: 1008,1010, 1020, 1026 Production: ERW + DOM Steel Grade and Chemical Compositions: Steel Grade C Mn P S Si Cr Mo max max max max min 1008 0.10 0.5 0.035 0.035 1010 0.08-0.13 0.30-0.60 0.035 0.035 1018 0.14-0.20 0.30-0.60 0.035 0.035 1020 0.17-0.23 0.30-0.60 0.035 0

Exhaust pipes aluminized Steel Tube for Exhaust System Product name: Aluminized Steel Tube for Exhaust System Keyword:aluminized steel pipe,aluminized exhaust pipe,aluminized steel exhaust pipe,aluminized steel tube Group: welded steel tube Standard:JIS G3445-2006, EN10130 material: SA1D, DC04, etc. Size range:OD,5-420mm,WT,0.5-50mm,Length, max 12m Application:Exhaust system Technique: ERW Surface:coating with aluminum 80g/120g price:8000-9000RMB/ton MOQ:10tons Deliver time

Double Wall Galvanized Bundy Tube WithZinc Coating For Automobile Brake 1. Standard GM123M, GM124M, TS7600G, GB 11258-89 2. Steel Grade/Steel Material/Steel Number: Low carbon steel, such as SPCCBLDBLC 3. Raw Material: Cold rolled low carbon steel strip 4. Characteristic: Good Surface Quality, Uniform coating No coating burr Stable quality Excellent corrosion resistance TORICH QUALITY ASSURANCE 5. Application: Brake tube on automobile 6. Specifications: OD(mm) OD tolerance(mm

TORICH GM123M GM124M Galvanized Double Wall Bundy Tube With Zinc Coating For Automobile Brake 1. Standard GM123M, GM124M, TS7600G, GB 11258-89 2. Steel Grade/Steel Material/Steel Number: Low carbon steel, such as SPCC BLD BLC 3. Raw Material: Cold rolled low carbon steel strip 4. Characteristic: Good Surface Quality, Uniform coating No coating burr Stable quality Excellent corrosion resistance TORICH QUALITY ASSURANCE 5. Application: Brake tube on automobile 6. Specifications

TORICH SAEJ526 PVF/Copper Coating Single Wall Bundy Tube For Brake system 1. Standard SAEJ526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1,SPCC,SPCD, SPCEN, ST14, ST15, ST16,DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per

TORICH EN10305-2 E155,E195,E235,E275,E355 Welded Cold Drawn DOM Steel Tubes Steel Grade/Steel Material: E155 E195 E235 E275 E355 Delivery Condition: 1 BK Cold finished(hard) 2 BKW Cold finished(soft) 3 BKS Cold finished and stress-relieved 4 GBK Annealed 5 NBK Normalized Size Range: O.D.:6-350mm W.T.:1-35mm L:max12000mm Characteristic: Good concentricity Good OD and ID tolerance High precision Stable quality Smooth roughness DOM Steel Tube Production Process: Raw material →

SAE J526 Carbon Welded Steel Tube Mechanical Coil Tubing for Auto Spec: Material:C Si Mn P S Size Range:OD:3.18-18mm WT:0.5-1.2mm General Length:1-200m Tolerance: According to the following tables or customers’ request. Table 1 Outer diameter, wall thickness and theoretical weight OD/mm WT/mm 0.30 0.40 0.50 0.60 0.65 0.70 0.80 0.90 1.00 1.30 theoretical weight /(kg/m) 3.18 0.0213 0.0274 0.0330 4.00 0.0274 0.0355 0.0432 0.0503 4.76 0.0330 0.0430 0.0525 0.0616 0.0659 0.0701 5

EN10217-1 P235TR1 P195TR1 Carbon Steel Welded Pipe For Pressure Purposes EN10217-1 Welded steel tubes for pressure purposes - Technical delivery conditions - Part 1: Non-alloy steel tubes with specified room temperature properties Since 2nd century, the welding seam quality increased a lot with fast development of excellent quality steel coil production, welding technology and inspection technology improvement, more welding steel tube sizes are available, and gradually widely
